*Italy Advanced DC Inverter Technology Supply Smoothness Control
型號 | YAPB-135HI | YAPB-210HI | YAPB-260HI | YAPB-360HI | YAPB-260HIS | YAPB-360HIS | |||||||||
Heating Capacity in A27/W27℃(Min-Max) 制熱量 | KW | 3.5-13.5 | 5-21 | 7-26 | 9-36 | 7-26 | 9-36 | ||||||||
COP 能效 | 6-16 | 6.1-16.1 | 6-15.5 | 6-16 | 6-15.5 | 6-16 | |||||||||
Heating Capacity in A15/W26℃(min-max) 制熱量 | KW | 2-9.5 | 3-14.5 | 4-18 | 6-24 | 4-18 | 6-24 | ||||||||
COP 能效 | 4.5-8 | 4.6-8.1 | 4.5-8.1 | 4.5-8 | 4.5-8.1 | 4.5-8 | |||||||||
Heating Input Power(min-max) 輸入功率 | KW | 0.22-2.2 | 0.4-3.4 | 0.5-4.3 | 0.75-6 | 0.5-4.3 | 0.75-6 | ||||||||
Rated Heating Running Current 額定電流 | A | 1-10 | 1.8-15.5 | 2.3-21 | 3.4-27.3 | 0.9-8.2 | 1.3-10.7 | ||||||||
Power Supply 電源 | V/Ph/Hz | 220~230V/1Ph/50Hz | 380~415V/3Ph/50Hz |
